Oracle X5-2L Service Manual page 123

a. Power off the server and disconnect the power cords from the server power
supplies.
See "Powering Down the Server" on page
b. Extend the server into maintenance position.
See "Extend the Server to the Maintenance Position" on page
c. Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See "Electrostatic Discharge Safety" on page
Remove the server top cover.
d.
See "Remove the Server Top Cover" on page
2. To remove a USB flash drive, grasp the flash drive and pull it from the slot.
If your server is configued with Oracle System Assistant software, it is located on the
Note -
USB flash drive in the bottom USB slot. Before removing the Oracle System Assistant USB
flash drive, see "Servicing the Oracle System Assistant USB Flash Drive" on page
Remove an Internal USB Flash Drive
55.
61.
52.
64.
Servicing CRUs That Require Server Power-Off
122.
123
