Remove SAS Storage Drive Cables

Related Information
"Servicing Storage Drives and Rear Drives (CRU)" on page 71
■
"Servicing the Front and Rear Storage Drive Backplanes (FRU)" on page 146
■
"Servicing NVMe Cables (FRU)" on page 174
■
Remove SAS Storage Drive Cables
1. Prepare the server for service.
a. Power off the server and disconnect the power cords from the power
supplies.
See
b. Extend the server to the maintenance position.
See
c. Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See
Remove the server top cover.
d.
See
e. Open the server fan assembly door and remove fan modules.
See
f. Swivel the air baffle into the upright position to allow access to the SAS
storage drive cables.
Depending on your server's storage drive configuration, do one of the
g.
following:
■
■
168 Oracle Server X5-2L Service Manual • May 2015
"Powering Down the Server" on page
"Extend the Server to the Maintenance Position" on page
"Electrostatic Discharge Safety" on page
"Remove the Server Top Cover" on page
"Remove a Fan Module" on page
If your server is configured with twenty-four 2.5-inch storage drives or
twelve 3.5-inch storage drives, remove the server's front fan assembly
door cover.
See "Remove the Fan Assembly Door From the Server" on page
If your server is configured with eight 2.5-inch storage drives, remove
the server's disk cage cover.
55.
61.
52.
64.
89.
65.
