Monitoring System Components
Component Name (Oracle ILOM
CLI Targets)
/SYS/MB/T_CORE_NET01
/SYS/MB/T_CORE_NET23
/SYS/MB/T_IN_PS
/SYS/SP
/SYS/SP/OK
/SYS/SP/NET[0-1]
Related Information
"System Chassis Components" on page 295
■
"Cooling Unit Components" on page 296
■
"Disk Backplane Components" on page 297
■
"Memory Device Components" on page 298
■
"Power Unit Components" on page 299
■
"Processor Components" on page 300
■
"System Firmware Components" on page 302
■
"Hard Disk Drive Components" on page 303
■

System Firmware Components

The following table lists the system firmware components.
Component Name
(Oracle ILOM CLI Target)
/SYS/MB/BIOS
/SYS/MB/CPLD
302 Oracle Server X5-2L Service Manual • May 2015
IPMI Type Description
■ Zone 0 – PCIe slot 5
■ Zone 1 – PCIe slot 4
■ Zone 2 – PCIe slot 1
Threshold Gigabit Ethernet controller die
sensor temperature
Threshold Gigabit Ethernet controller die
sensor temperature
Threshold Power supply unit (PSU) inlet
sensor temperature, located directly in
front of the PSU 0 air inlet.
FRU Service processor FRU
Indicator SP OK LED
FRU SP Ethernet FRU
IPMI Type Description
FRU BIOS FRU
FRU Mainboard CPLD/FPGA firmware
Values (if applicable)
CPU 0, NET 0+1 Degrees
Celsius
CPU 1, NET 2+3 Degrees
Celsius
Degrees Celsius
Color: Green
Location: Front panel
On: SP is operating.
Off: SP requires service.
