Hard Disk Drive Components

The following table lists the hard disk drive (HDD) components.
Component Name (Oracle ILOM
CLI Targets)
/SYS/MB/RHDD[0-1]
/SYS/MB/RHDD[0-1]/PRSNT
/SYS/MB/RHDD[0-1]/SERVICE
/SYS/MB/RHDD[0-1]/OK2RM
/SYS/MB/RHDD[0-1]/STATE
/SYS/DBP/HDD[0-x]
/SYS/DBP/HDD[0-x]/PRSNT
IPMI Type Description
FRU Rear hard disk drive FRU
Discrete Rear hard disk drive presence
sensor
Indicator Rear hard disk drive Service
Required LED
Indicator Rear hard disk drive OK to
Remove LED
Discrete Rear hard disk drive state
sensor
FRU Hard disk drive FRU
Discrete Hard disk drive presence
sensor
Monitoring Components and Identifying SNMP Messages
Monitoring System Components
Values (if applicable)
From host
01h-ENTITY_PRESENT,
02h-ENTITY_ABSENT
Color: Amber
Location: Rear HDD
Off: Normal
On: Hard disk drive (HDD)
was diagnosed as faulty.
Color: Blue
Location: Rear HDD
Off: Normal
On: OK to remove
02h-DRIVE_FAULT
04h-
PREDICTIVE_FAILURE
08h-HOT_SPARE
From host
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
