It is not necessary to completely remove the storage drives from the server; simply pull
Note -
them out far enough to disengage them from the disk backplane. If you do remove the storage
drives from the server, make a note of their locations so that you can reinstall them in the same
locations.
Disconnect the cables from the storage drive backplane [1].
3.
Disconnect the two SAS cables from the storage drive backplane.
a.
b.
Disconnect the power cable from the storage drive backplane.
Remove the Storage Drive Backplane for Rear-Mounted Storage Drives
Servicing FRUs
163
