Servicing the Oracle Storage 12 Gb/s SAS PCIe RAID HBA Card (FRU)

Servicing the Oracle Storage 12 Gb/s SAS PCIe RAID HBA
Card (FRU)
These sections describe how to service and install the Oracle Storage 12 Gb/s SAS PCIe RAID
HBA card.
Caution -
replaced only by authorized Oracle Service personnel.
Caution -
electrostatic discharge. This sensitivity can cause the components to fail. To avoid
damage, ensure that you follow antistatic practices as described in
Measures" on page
Caution -
PCIe cards. You must disconnect all power cables from the system before performing these
procedures.
This section covers the following procedures:
"Remove the Oracle Storage 12 Gb/s SAS PCIe RAID HBA Card" on page 180
■
"Install the Oracle Storage 12 Gb/s SAS PCIe RAID HBA Card" on page 184
■
Related Information
"Servicing SAS Cables (FRU)" on page 167
■
Remove the Oracle Storage 12 Gb/s SAS PCIe
RAID HBA Card
Prepare the server for service.
1.
a. Power off the server and disconnect the power cords from the power
supplies.
See
Extend the server to the maintenance position.
b.
180 Oracle Server X5-2L Service Manual • May 2015
The Oracle Storage 12 Gb/s SAS PCIe RAID HBA card should be removed and
These procedures require that you handle components that are sensitive to
64.
Ensure that all power is removed from the server before removing or installing
"Powering Down the Server" on page
"Take Antistatic
55.
