About System Components
System Components
FIGURE 5
Figure
Legend
1a
1b
1c
2a
2b
2c
20
Oracle Server X5-2L Service Manual • May 2015
Description
Twelve 3.5-inch storage drives
Twenty-four 2.5-inch storage drives
Eight 2.5-inch storage drives
Front disk backplane for twelve 3.5-inch drives
Front disk backplane for twenty-four 2.5-inch drives
Front disk backplane for eight 2.5-inch drives
