Related Information

"Servicing Storage Drives and Rear Drives (CRU)" on page 71
■
"Servicing the Front and Rear Storage Drive Backplanes (FRU)" on page 146
■
"Servicing SAS Cables (FRU)" on page 167
■

Remove NVMe Cables

Prepare the server for service.
1.
a. Power off the server and disconnect the power cords from the power
supplies.
See "Powering Down the Server" on page
b. Extend the server to the maintenance position.
See "Extend the Server to the Maintenance Position" on page
c. Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See "Electrostatic Discharge Safety" on page
Remove the server top cover.
d.
See "Remove the Server Top Cover" on page
e. Open the server fan assembly door and remove the fan modules.
See "Remove a Fan Module" on page
f. Swivel the air baffle into the upright position to allow access to the NVMe
cables.
g. Depending on your server's storage drive configuration, do one of the
following:
■ If your server is configured with twenty-four 2.5-inch storage drives,
remove the server's front fan assembly door cover.
See "Remove the Fan Assembly Door From the Server" on page
If your server is configured with eight 2.5-inch storage drives, remove
■
the server's disk cage cover.
55.
61.
52.
64.
89.
Remove NVMe Cables
65.
Servicing FRUs 175
