Remove Antistatic Measures

2. Using a No. 2 Phillips screwdriver, install and tighten the twelve screws (three on
each top side of the chassis, and three on each side of the chassis) to secure the
disk cage cover [2].
Related Information
"Remove the Server Top Cover" on page 64
■
"Install the Server Top Cover" on page 226
■
"Remove the Disk Cage Cover From the Server" on page 67
■
Remove Antistatic Measures
1. Remove any antistatic straps or conductors from the server chassis.
2. Remove the antistatic wrist strap from yourself.
Related Information
"Take Antistatic Measures" on page 64
■

Reinstall the Server in the Rack

After servicing the system, reinstall it into the rack.
Caution -
Caution -
carry the chassis and install it in the rack.
1. Lift the server from the antistatic mat, and reinstall the server into the rack.
Refer to
installation instructions specific to your rackmount kit.
2. If the cable management arm (CMA) is not installed, that is, you removed it
because you removed the server completely out of the rack, install the CMA.
For installation instructions for the CMA, refer to
"Oracle Server X5-2L Installation Guide
If the cables are disconnected from the rear of the server, that is, you
3.
disconnected the cables because you removed the server completely out of the
rack, reconnect the cables.
230 Oracle Server X5-2L Service Manual • May 2015
Deploy any rack anti-tilt mechanism before installing the server into the rack.
The server weighs approximately 63 pounds (28.5 kg). Two people are required to
"Installing the Server Into a Rack" in "Oracle Server X5-2L Installation Guide "
"Install the Cable Management Arm" in
".
for the
