System Chassis Components

The following table lists the system chassis components.
Component Name (Oracle
ILOM CLI Targets)
/SYS
/SYS/UUID
/SYS/ACPI
/SYS/VPS
/SYS/VPS_CPUS
/SYS/VPS_MEMORY
/SYS/VPS_FANS
/SYS/INTSW
/SYS/T_AMB
/SYS/TEMP_FAULT
/SYS/OK
/SYS/SERVICE
IPMI Type Description
FRU Product information only
FRU Unique system ID
State sensor Advanced Configuration and
Power Interface
Threshold Virtual power sensor
sensor
Threshold Virtual power sensor (CPUs)
sensor
Threshold Virtual power sensor (Memory)
sensor
Threshold Virtual power sensor (Fans)
sensor
Discrete Chassis intrusion switch
sensor
Threshold Ambient temperature on system
sensor motherboard, located behind
the left side front SIS indicator.
Indicator Temperature Fault LED
Indicator Power OK LED
Indicator Service Required LED
Monitoring Components and Identifying SNMP Messages
Monitoring System Components
Values (if applicable)
Derived from host MAC address.
Used for PXE boot and licensing.
(hidden)
01h-ACPI_ON_WORKING
20h-ACPI_SOFT_OFF
Watts
Watts
Watts
Watts
01h-Deasserted
02h-Asserted
Degrees Celsius
Color: Amber
Location: Front panel
Off: Normal
On: Chassis overtemp fault
Color: Green
Location: Front panel
Off: Power is off.
Standby blink: Standby power is on;
Oracle ILOM SP is running.
Slow blink: Startup sequence
initiated on host.
On: Host is booting OS or running
the OS.
Color: Amber
