Remove the DVD Drive

This section covers the following procedures:
"Remove the DVD Drive" on page 188
■
"Install the DVD Drive" on page 190
■
Related Information
"Servicing Fan Modules (CRU)" on page 89
■
Remove the DVD Drive
Remove media from the drive.
1.
Prepare the server for service.
2.
Power off the server and disconnect the power cords from the server power
a.
supplies.
See
b. Extend the server into the maintenance position.
See
c. Attach an antistatic wrist strap.
See
Remove the disk cage cover.
d.
See
3. If necessary, remove fan modules 2 and 3 from the chassis.
See "Remove a Fan Module" on page
4. Reach into the server directly behind the DVD drive, and disconnect the power
and DVD data connectors from rear of the DVD drive.
188 Oracle Server X5-2L Service Manual • May 2015
"Powering Down the Server" on page
"Extend the Server to the Maintenance Position" on page
"Electrostatic Discharge Safety" on page
"Remove the Disk Cage Cover From the Server" on page
55.
52.
89.
61.
67.
