Selecting The Correct Processor Removal And Replacement Tool - Oracle X5-2L Service Manual

Servicing Processors (FRU)
Caution -
processor. You must disconnect the power cables from the system before performing these
procedures.
Caution -
discharge. This sensitivity can cause the component to fail. To avoid damage, ensure that
you follow electrostatic discharge safety measures and antistatic practices. See
Discharge Safety" on page
Note -
in the processor socket 1 (P1). To protect the delicate processor socket pins, the cover that
comes on the motherboard from manufacturing is left in place.
This section covers the following topics:
"Selecting the Correct Processor Removal and Replacement Tool" on page 130
■
"Remove a Processor" on page 134
■
"Install a Processor" on page 140
■
Related Information
"Servicing the DIMMs (CRU)" on page 101
■
Selecting the Correct Processor Removal and
Replacement Tool
Caution -
to remove and replace a processor; otherwise, the processor or the processor socket might
be damaged. Additionally, do not use a tool that is designed for earlier generations of Intel
processors (CPUs). If you use an earlier generation tool, the processor will only be partially
held by the tool and it could fall from the tool, which could damage the processor socket.
Selecting the correct processor removal and replacement tool is a two-step process. First you
determine the size of the processor that is being replaced, then you select the removal and
replacement tool that fits that size.
The processors supported by the Oracle Server X5-2L are available in two sizes. The processors
with 10 or fewer cores are smaller than the processors with 12 or more cores. You can
determine the size of the processor that you are going to remove and replace in either of these
two ways:
Use Oracle Integrated Lights Out Manager (ILOM) 3.2 to display processor information.
■
130 Oracle Server X5-2L Service Manual • May 2015
Ensure that all power is removed from the server before removing or installing a
This procedure requires that you handle components that are sensitive to electrostatic
52.
On single-processor systems, neither a heatsink nor a processor filler cover are installed
The correct color-coded processor removal and replacement tool must be used
"Electrostatic
