Monitoring System Components
Component Name (Oracle ILOM CLI
Targets)
/SYS/PS[0-1]/P_IN
/SYS/PS[0-1]/P_OUT
/SYS/PS[0-1]/V_IN
/SYS/PS[0-1]/V_12V
/SYS/PS[0-1]/V_12V_STBY
/SYS/PS[0-1]/T_OUT
Related Information
"System Chassis Components" on page 295
■
"Cooling Unit Components" on page 296
■
"Disk Backplane Components" on page 297
■
"Memory Device Components" on page 298
■
"Processor Components" on page 300
■
"System Board Components" on page 301
■
"System Firmware Components" on page 302
■
"Hard Disk Drive Components" on page 303
■

Processor Components

The following table lists the processor (CPU) components.
Component Name (Oracle
ILOM CLI Targets)
/SYS/MB/P[0-x]
/SYS/MB/P[0-x]/PRSNT
/SYS/MB/P[0-x]/SERVICE
300 Oracle Server X5-2L Service Manual • May 2015
IPMI Type
Power sensor
Power sensor
Voltage sensor
Voltage sensor
Voltage sensor
Temperature sensor
IPMI Type Description
FRU Host CPU FRU
Discrete Host CPU is present.
sensor
Indicator Host CPU Service
Required LED
Description Values (if applicable)
Power supply input out-of-
range
Configuration error
Input power draw Watts
Output power Watts
Input voltage Volts
12V output voltage Volts
12V standby Volts
output voltage
Ambient Degrees Celsius
temperature
Values (if applicable)
01h-ENTITY_PRESENT
02h-ENTITY_ABSENT
Color: Amber
Location: Mainboard
Off: Normal
On: Processor was diagnosed as
faulty.
