Oracle Netra X5-2 Installation Manual

Hide thumbs Also See for Netra X5-2:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
Netra Server X5-2 Installation Guide
Part No: E53598-04
June 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Netra X5-2 and is the answer not in the manual?

Questions and answers

Related Manuals for Oracle Netra X5-2

Summary of Contents for Oracle Netra X5-2

  • Page 1 Netra Server X5-2 Installation Guide Part No: E53598-04 June 2016...
  • Page 3 Oracle. Oracle Corporation and its affiliates will not be responsible for any loss, costs, or damages incurred due to your access to or use of third-party content, products, or services, except as set forth in an applicable agreement between you and Oracle.
  • Page 4 Oracle Corporation et ses affiliés déclinent toute responsabilité ou garantie expresse quant aux contenus, produits ou services émanant de tiers, sauf mention contraire stipulée dans un contrat entre vous et Oracle. En aucun cas, Oracle Corporation et ses affiliés ne sauraient être tenus pour responsables des pertes subies, des coûts occasionnés ou des dommages causés par l’accès à...

  • Page 5: Table Of Contents

    Contents Using This Documentation .................  7 Understanding the Server ...................  9 Installation Task Overview ................ 9 Server Overview ...................  10 Front Panel Components (Installation) ............... 12 Rear Panel Components (Installation) ...............  14 Confirming Specifications .................  17 Physical Specifications ...................  17 Electrical Specifications .................. 18 Input Power Information ................. 19 Overcurrent Protection Requirements .............. 20 DC Power Source, Power Connection, and Grounding Requirements ......
  • Page 6 Contents ▼ Install the Server (4-Post, 19-Inch Hardmount Rack Kit) ...... 33 Installing the 19-Inch Sliding Rail Kit With the CMA ..........  37 19-Inch Sliding Rail Kit With the CMA ............  38 ▼ Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit) .. 39 Installing the 19-Inch Hardmount Kit (2-Post Rack) ..........

  • Page 7: Using This Documentation

    Using This Documentation Overview – Provides specifications and describes how to install and power on Oracle's ■ Netra Server X5-2 server for the first time. Audience – Technicians, system administrators, and authorized service providers. ■ Required knowledge – Experience installing hardware.
  • Page 8 Netra Server X5-2 Installation Guide • June 2016...

  • Page 9: Understanding The Server

    Understanding the Server These topics provide an installation overview and information about the server features. “Installation Task Overview” on page 9 ■ “Server Overview” on page 10 ■ “Front Panel Components (Installation)” on page 12 ■ “Rear Panel Components (Installation)” on page 14 ■...

  • Page 10: Server Overview

    Server Overview Step Description Links Install any optional components that you ordered. “Optional Components” on page 29 Review the rack cautions. “Rack Cautions” on page 30 Install the server in a 4-post or 2-post rack. “Installing the Server” on page 29 Review cabling requirements and port information.
  • Page 11 Only available in the 6-drive model: One tray-loading, slimline SATA DVD drive, supporting CD-R/- RW, CD+R/+RW, DVD-R/-RW, DVD+R/+RW (when used with supported media). Service processor Internal Pilot3 BMC running Oracle ILOM service processor firmware with provisions for: ■ Oracle ILOM 3.2.4 ■ 2D graphics (HD-15 VGA connector) ■...

  • Page 12: Front Panel Components (Installation)

    Front Panel Components (Installation) Component Description Power supplies Depending on the model, one of the following configurations: ■ 2 hot-swappable AC supplies (maximum 1200 W) ■ 2 hot-swappable DC supplies (maximum 1200 W) Note - Mixing of AC and DC power supplies is not allowed. Cooling Front-to-back forced air, with active fan speed control.
  • Page 13 Front Panel Components (Installation) Description Links ■ Service Required LED ■ System OK LED ■ Power button ■ SP LED ■ Rear PS fault LED Telco alarm indicators: ■ Critical LED ■ Major LED ■ Minor LED ■ User LED Eight SAS drive slots or four SAS drive slots and four NMVe “Servicing SAS Drives”...

  • Page 14: Rear Panel Components (Installation)

    Rear Panel Components (Installation) Description Links ■ Rear PS fault LED Telco alarm indicators: ■ Critical LED ■ Major LED ■ Minor LED ■ User LED “Servicing the DVD Drive” in Netra Server X5-2 Service Manual Two USB 2.0 connectors “USB Ports”...
  • Page 15 Rear Panel Components (Installation) Description Links Hot-swappable power supply (AC or DC), PS1 “Servicing Power Supplies” in Netra Server X5-2 Service Manual Hot-swappable power suppiy (AC or DC), PS0 “Servicing Power Supplies” in Netra Server X5-2 Service Manual The number of available PCIe slots depends on the CPU “Servicing PCIe Cards”...
  • Page 16 Netra Server X5-2 Installation Guide • June 2016...

  • Page 17: Confirming Specifications

    Confirming Specifications These topics provide information about the server specifications. “Physical Specifications” on page 17 ■ “Electrical Specifications” on page 18 ■ “Input Power Information” on page 19 ■ “Overcurrent Protection Requirements” on page 20 ■ “DC Power Source, Power Connection, and Grounding Requirements” on page 21 ■...

  • Page 18: Electrical Specifications

    “Airflow Precautions” on page 23 ■ Electrical Specifications The values in this table are for the power supplies. Use the online power calculator to determine the power consumption of a server with your configuration: http://www.oracle.com/goto/ powercalculators. Parameter Voltage (nominal) 100 VAC (Japan only) −48 or −60 VDC (−40 to −72 VDC range)

  • Page 19: Input Power Information

    Input Power Information The ports of this equipment or subassembly are suitable for connection to intra- Caution - building or unexposed wiring or cabling only. The intra-building port(s) of the equipment or subassembly must not be metallically connected to interfaces that connect to the outside plant wiring.

  • Page 20: Overcurrent Protection Requirements

    Overcurrent Protection Requirements “Electrical Specifications” on page 18 ■ “Overcurrent Protection Requirements” on page 20 ■ “DC Power Source, Power Connection, and Grounding Requirements” on page 21 ■ “Environmental Requirements” on page 22 ■ “Acoustic Noise Emissions” on page 23 ■...

  • Page 21: Dc Power Source, Power Connection, And Grounding Requirements

    DC Power Source, Power Connection, and Grounding Requirements DC Power Source, Power Connection, and Grounding Requirements The server power source and connections must meet the following requirements. The DC version of the server must be installed in a restricted-access location. According Note - to the intent of the U.S.

  • Page 22: Environmental Requirements

    Environmental Requirements “Input Power Information” on page 19 ■ “Overcurrent Protection Requirements” on page 20 ■ “Environmental Requirements” on page 22 ■ “Acoustic Noise Emissions” on page 23 ■ “Airflow Precautions” on page 23 ■ Environmental Requirements Netra rackmounted servers are certified to meet these worst-case operating conditions Caution - only when using an approved rackmount kit.

  • Page 23: Acoustic Noise Emissions

    Acoustic Noise Emissions “Airflow Precautions” on page 23 ■ Acoustic Noise Emissions The declared noise emissions for the server are in accordance with ISO 9296 standards. Parameter Operating Noise Emissions Acoustic sound power LwA (dBA) 75 dBA (AC server) 75 dBA (DC server) Related Information “Physical Specifications”...
  • Page 24 Airflow Precautions Follow these guidelines to ensure unrestricted airflow in the server: Adhere to the minimum airflow clearance specifications. See “Physical ■ Specifications” on page Install the server so the front faces the cool aisle and the rear faces the warm aisle. ■...

  • Page 25: Preparing For Installation

    Preparing for Installation These topics describe how to prepare to install the server. “Shipping Kit Inventory” on page 25 ■ “Handling Precautions” on page 26 ■ “ESD Precautions” on page 27 ■ “Tools Needed for Installation” on page 27 ■ Related Information “Understanding the Server”...

  • Page 26: Handling Precautions

    Handling Precautions Hardware, cables, documents, and connectors ■ Any optional components that were ordered with the server ■ Related Information “Handling Precautions” on page 26 ■ “ESD Precautions” on page 27 ■ “Tools Needed for Installation” on page 27 ■ “Rack Cautions”...

  • Page 27: Esd Precautions

    ESD Precautions “Optional Components” on page 29 ■ “Rack Cautions” on page 30 ■ “Stabilize the Rack” on page 31 ■ ESD Precautions Electronic equipment is susceptible to damage by static electricity. Use a grounded antistatic wrist strap or foot strap, or equivalent safety equipment to prevent ESD when you install or service the server.
  • Page 28 Tools Needed for Installation Computer, such as a laptop running terminal emulation software ■ Patch panel connected to a terminal server ■ Cables needed to connect the console device to the SER MGT port ■ Related Information “Shipping Kit Inventory” on page 25 ■...

  • Page 29: Installing The Server

    Installing the Server These topics describe how to install the server into an equipment rack. Step Description Links Install optional components. “Optional Components” on page 29 Review cautions. “Handling Precautions” on page 26 Stabilize the rack. “Stabilize the Rack” on page 31 Install the server in a rack.

  • Page 30: Rack Cautions

    Rack Cautions Related Information “Shipping Kit Inventory” on page 25 ■ “Rack Cautions” on page 30 ■ Rack Cautions Equipment Loading. Always load equipment into a rack from the bottom up so that Caution - the rack does not become top-heavy and tip over. Deploy your rack's antitip bar to prevent the rack from tipping during equipment installation.

  • Page 31: Stabilize The Rack

    Stabilize the Rack “Stabilize the Rack” on page 31 ■ Stabilize the Rack To reduce the risk of personal injury, stabilize the rack cabinet and extend all antitilt Caution - devices before installing the server. Refer to your rack documentation for detailed instructions for the following steps. In this document, the term rack means either an open rack or a closed cabinet.

  • Page 32: 19-Inch Hardmount Kit (4-Post Rack)

    Stabilize the Rack “Handling Precautions” on page 26 ■ “Rack Cautions” on page 30 ■ 19-Inch Hardmount Kit (4-Post Rack) Description Rear mount flanges (2) Screws Rear mount support brackets (2) Hardmount brackets (2) Netra Server X5-2 Installation Guide • June 2016...

  • Page 33: Install The Server (4-Post, 19-Inch Hardmount Rack Kit)

    Install the Server (4-Post, 19-Inch Hardmount Rack Kit) Related Information “Install the Server (4-Post, 19-Inch Hardmount Rack Kit)” on page 33 ■ “Tools Needed for Installation” on page 27 ■ “Handling Precautions” on page 26 ■ “Rack Cautions” on page 30 ■...
  • Page 34 Install the Server (4-Post, 19-Inch Hardmount Rack Kit) Use four M5 x 4.5 mm flathead Phillips screws for each bracket. Measure the depth of the rack. The measurement is used in the next step. Install the rear mount support brackets at the rear of the server, extending the rear mount support brackets to the measured depth of the rack.
  • Page 35 Install the Server (4-Post, 19-Inch Hardmount Rack Kit) Use two to three of the supplied M4 x 0.5 x 5 mm panhead Phillips screws for each bracket, depending on the rack depth. Lift the server to the desired location in the rack. Secure the front of the hardmount brackets.
  • Page 36 Install the Server (4-Post, 19-Inch Hardmount Rack Kit) Use two screws for each post. Secure the rear mount support brackets to the rear of the rack. Use two screws for each rear mount support bracket. Netra Server X5-2 Installation Guide • June 2016...

  • Page 37: Installing The 19-Inch Sliding Rail Kit With The Cma

    Installing the 19-Inch Sliding Rail Kit With the CMA Connect required and optional cables. “Connecting Cables” on page Consider your next step: ■ For existing servers, return the server to operation by following the steps in the service manual. For new servers, continue the installation by following the steps in ■...

  • Page 38: 19-Inch Sliding Rail Kit With The Cma

    Installing the 19-Inch Sliding Rail Kit With the CMA 19-Inch Sliding Rail Kit With the CMA Description Threaded screw plates (4) Screw, nut, and U-clip packages Cable management arm Rear, long L-Brackets (2) Front, short L-brackets (2) Slide assemblies (2) Glide assemblies (2) Hardmount brackets (2) from standard rail kit Related Information...

  • Page 39: Install The Server (4-Post, 19-Inch Sliding Rails With Cma Rack Kit)

    Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit) “Handling Precautions” on page 26 ■ “Rack Cautions” on page 30 ■ Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit) You must install the server into a rack following these instructions for the 4-post, Caution - 19-inch sliding rails with CMA kit.
  • Page 40 Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit) Use four M5 x 4.5 mm flathead Phillips screws for each side. Disassemble the sliding rails by pressing the release buttons and pulling the rail glides out of the sliding rails. Attach the rail glides to the hardmount brackets.
  • Page 41 Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit) Use four M4 x 5 mm panhead screws for each rail glide. Loosely install the L-brackets to the sliding rails. Installing the Server...
  • Page 42 Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit) Use four M5 x 12 mm panhead screws, four flat washers, four star washers, and four nuts for each L-bracket. Loosely install the threaded screw plate and cage nuts in the four posts at the appropriate height.
  • Page 43 Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit) For square-hole racks, use two cage nuts and two M6 shoulder screws for ■ each threaded screw plate. For round-hole racks, use two U-clips and two M6 shoulder screws for each ■...
  • Page 44 Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit) These cage nuts are used to secure the server into the rack. The security screws go through the hardmount brackets and in to the cage nuts. For round-hole racks, install one U-clip per post directly above and below ■...
  • Page 45 Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit) For square-hole racks, install the assemblies as shown here. ■ Installing the Server...
  • Page 46 Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit) For round-hole racks, install the assemblies as shown here. ■ Secure the L-bracket assemblies to the posts. Tighten the sliding rail screws. Extend the slide assemblies until they lock open, and slowly install the server into the slide assemblies.
  • Page 47 Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit) This illustration shows the square-hole rack. This step is the same for the round-hole rack. Press the release buttons, and slide the server completely into the rack. This step is the same for the round-hole rack. Attach the right and left sides of the CMA to the rear of the slide assembly (right) and server (left).
  • Page 48 Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit) The green, spring-loaded handles should point inward. Pull the green handles out and release it when the holes are aligned. The left CMA flange fits into key-hole notches on the end of the left glide rail.
  • Page 49 Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit) This illustration shows the square-hole rack. This step is the same for the round-hole rack. Install the security screws to secure the server into the rack. Installing the Server...
  • Page 50 Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit) For square-hole racks, use one M6 x 13 mm shoulder screw for each post. ■ Netra Server X5-2 Installation Guide • June 2016...
  • Page 51 Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit) For round-hole racks, use one M6 x 13 mm shoulder screw for each post. ■ Consider your next step: For existing servers, return the server to operation by following the steps in ■...

  • Page 52: Installing The 19-Inch Hardmount Kit (2-Post Rack)

    Installing the 19-Inch Hardmount Kit (2-Post Rack) Installing the 19-Inch Hardmount Kit (2-Post Rack) Use these topics to install the server using an optional 19-inch hardmount rack kit into a 19-inch wide, 2-post rack. “19-Inch Hardmount Rack Kit (2-Post Rack)” on page 52 ■...

  • Page 53: Install The Server (2-Post, 19-Inch Hardmount Rack Kit)

    Install the Server (2-Post, 19-Inch Hardmount Rack Kit) Description Screws Side brackets (2) Related Information “Install the Server (2-Post, 19-Inch Hardmount Rack Kit)” on page 53 ■ “Tools Needed for Installation” on page 27 ■ “Handling Precautions” on page 26 ■...
  • Page 54 Install the Server (2-Post, 19-Inch Hardmount Rack Kit) Secure the side brackets to the sides of the server. Use four M5 x 7 SEM screws for each side bracket. Lift the server into the rack. Using two screws for each bracket, secure the front of the server to the front of the rack.
  • Page 55 Install the Server (2-Post, 19-Inch Hardmount Rack Kit) The size of the screws varies, depending on your rack. (Optional) If your environment contains especially high vibrations, use the rear plates to further secure the server to the rack. The rear plates attach to the rear of the post and to one of the three sets of eyelets on each side bracket, depending on the thickness of the post.
  • Page 56 Install the Server (2-Post, 19-Inch Hardmount Rack Kit) Use two M3 x 8 SEM screws for each rear plate. The position varies depending on the thickness of the rail in the rack. For example, this figure shows where to install the screws for the optimum rack position on the rear plate.
  • Page 57 Install the Server (2-Post, 19-Inch Hardmount Rack Kit) The screw heads should be facing the rear of the server. The other side of the rear plate should be in front of the rack post. Tighten the screws to secure the rear plate to the set of eyelets on the side bracket.
  • Page 58 Install the Server (2-Post, 19-Inch Hardmount Rack Kit) Use two screws per post. The size of the screws varies, depending on your rack. Connect required and optional cables. “Connecting Cables” on page Consider your next step: For existing servers, return the server to operation by following the steps in ■...
  • Page 59 Install the Server (2-Post, 19-Inch Hardmount Rack Kit) Related Information “Tools Needed for Installation” on page 27 ■ “Handling Precautions” on page 26 ■ “Rack Cautions” on page 30 ■ Installing the Server...
  • Page 60 Netra Server X5-2 Installation Guide • June 2016...

  • Page 61: Connecting Cables

    Connecting Cables Perform the following tasks to connect and configure the network and serial ports before you apply power to the server. Step Description Links Review the available connections. “Available Connections” on page 61 Cable the SP. “Cable the SP” on page 64 “SER MGT Port”...
  • Page 62 Available Connections Use the information in this topic to plan for these connections. Then gather the required network addresses and cables. Caution - To comply with NEBS lightning requirements, all I/O connections (except the Ethernet and power connections) must be made using shielded cables, and both ends of the shield must be grounded.
  • Page 63 ■ An Ethernet cable to connect to the NET MGT RJ-45 connector. This port supports remote connections to port to your network. the SP using the Oracle ILOM CLI and web interface. ■ An IP address for this port (required from DHCP or a static address) By default, this port is configured to use DHCP or an IPv6 router to automatically obtain an IP address.

  • Page 64: Connecting Data And Management Cables

    Connecting Data and Management Cables Connecting Data and Management Cables These topics describe which ports you must cable before applying power to the server. “Available Connections” on page 61 ■ “Cable the SP” on page 64 ■ “Cable the Ethernet Ports” on page 65 ■...

  • Page 65: Cable The Ethernet Ports

    “10 Gigabit Ethernet Ports” on page The Oracle ILOM sideband management feature enables you to access the SP using Note - one of these Ethernet ports. Refer to the Oracle ILOM Administor's Guide for Configuration and Maintenance For Release 3.2.x at http://www.oracle.com/goto/ilom321/docs instructions.

  • Page 66: Identifying Ports

    ■ SER MGT Port The SER MGT RJ-45 port, located on the rear panel, provides an TIA/EIA-232 serial Oracle/ Cisco standard connection to the SP. For DTE-to-DTE communications, you can use the supplied RJ-45 to DB-9 crossover adapter with a standard RJ-45 cable to achieve the required null modem configuration.

  • Page 67: Net Mgt Port

    Identifying Ports Signal Description Signal Description Clear to Send Ground Data Carrier Detect Receive Data Transmit Data Data Terminal Ready Ground Ready to Send Do not attach a modem to this port. Caution - Related Information “Available Connections” on page 61 ■...

  • Page 68: Gigabit Ethernet Ports

    Green 10000 Mbits/sec The Oracle ILOM sideband management feature enables you to access the SP using Note - one of these Ethernet ports. Refer to the Oracle ILOM Administor's Guide for Configuration and Maintenance For Release 3.2.x at http://www.oracle.com/goto/ilom321/docs instructions.

  • Page 69: Usb Ports

    Identifying Ports Signal Description Signal Description Transmit/Receive Data 0 + Transmit/Receive Data 2 - Transmit/Receive Data 0 - Transmit/Receive Data 1 - Transmit/Receive Data 1 + Transmit/Receive Data 3 + Transmit/Receive Data 2 + Transmit/Receive Data 3 - Related Information “Available Connections”...

  • Page 70: Video Port

    Identifying Ports Signal Description Signal Description Data - Ground Related Information “Available Connections” on page 61 ■ “Rear Panel Components (Installation)” on page 14 ■ “SER MGT Port” on page 66 ■ “NET MGT Port” on page 67 ■ “10 Gigabit Ethernet Ports” on page 68 ■...
  • Page 71 Identifying Ports Signal Description Signal Description Green Ground VGA I C Serial Clock Blue Ground Related Information “Available Connections” on page 61 ■ “Rear Panel Components (Installation)” on page 14 ■ “SER MGT Port” on page 66 ■ “NET MGT Port” on page 67 ■...
  • Page 72 Netra Server X5-2 Installation Guide • June 2016...

  • Page 73: Powering On The Server The First Time

    As soon as the power cables are connected to the power source, the server goes into Caution - Standby mode and the Oracle ILOM SP initializes. Do not operate the server unless all fans, component heatsinks, air baffles, and the Caution - top cover are installed.
  • Page 74 Connect AC Power Cords The SP runs on the 3.3V standby voltage. As soon as power is connected, the SP powers on, runs diagnostics, and initializes the Oracle ILOM firmware. Note - If you do not connect a serial terminal or a terminal emulator, you will not see the system messages.

  • Page 75: Assembling Dc Power Cords And Applying Dc Power

    Assembling DC Power Cords and Applying DC Power Connect the AC power cords to both power supplies. When power is applied, the OK LED flashes while the SP initializes. After a few minutes, the OK LED slowly flashes, indicating that the server is in standby power mode. See “Front Panel Components (Installation)”...

  • Page 76: Connect The Chassis Ground Wire

    Connect the Chassis Ground Wire Step Description Links Connect the chassis to earth ground. “Connect the Chassis Ground Wire” on page 76 Build the DC power cords. “Assemble the DC Input Power Cord” on page 78 Connect the DC power cords to the DC power “Connect DC Power Cords”...
  • Page 77 Connect the Chassis Ground Wire Position and align the grounding lug on the two grounding studs at the rear of the chassis. Description Earth ground cable secured in the grounding lug M5 nuts Secure the grounding lug to the grounding studs using the two M5 nuts. Secure the other end of the grounding wire to the earth ground in the building.

  • Page 78: Assemble The Dc Input Power Cord

    Assemble the DC Input Power Cord Assemble the DC Input Power Cord Assemble one DC input power cable for each DC power input to your server. Verify that you have met these conditions: Install a DC power source that meets the server's input power specifications. “Electrical Specifications”...

  • Page 79: Power Source

    Assemble the DC Input Power Cord For each cable, you need the items shown in this illustration. These items are included in the shipping kit that came with your server. Locate the three wires coming from your DC power source that will be used for the connection to your server.
  • Page 80 Assemble the DC Input Power Cord Do not strip more than 1/2 in. (13 mm) from each wire. Doing so leaves uninsulated wire exposed from the DC connector after the assembly is complete. Description 1/2 in. (13 mm) maximum Open the cage clamp for this section of the DC input plug. Insert the cage clamp tool (or small screwdriver) into the rectangular hole directly above the hole in the DC input plug where you want to insert the first wire.

  • Page 81: Connect Dc Power Cords

    60 seconds if a terminal or terminal emulator is not connected to the SER MGT port before power is applied. Oracle ILOM will signal a fault if power is not applied to both supplies because, that is a Note - nonredundant condition.
  • Page 82 Power is immediately supplied to the SP, and the front panel SP OK/Fault LED flashes (see “Front Panel Components (Installation)” on page 12). The SP then runs diagnostics and initializes the Oracle ILOM firmware. Netra Server X5-2 Installation Guide • June 2016...

  • Page 83: Power On The Host For The First Time

    . . . -> After a brief delay, the Oracle ILOM prompt is displayed (->). At this point, there are many commands you can perform using the Oracle ILOM interface. Additional SP information, such as how to change the password and how to set up the SP network parameters is available in “Change the Oracle ILOM Root Password (Oracle ILOM...
  • Page 84 Either configure the preinstalled OS, or install and configure a different OS on the server. To install an OS on the Netra Server X5-2 from Oracle, refer to the Netra Server X5-2 Operating System Installation Guide.

  • Page 85: Glossary

    Glossary ACPI Advanced Configuration and Power Interface. ANSI SIS American National Standards Institute Status Indicator Standard. Alert standard format. Automatic system recovery. American wire gauge. basic assurance test. BIOS Basic Input Output System. Baseboard management controller. Memory buffer on board. chassis Refers to the server enclosure.
  • Page 86 Host bus adapter. Hardware Management Pack. host The part of the server with the CPU and other hardware that runs the Oracle Solaris OS and other applications. The term host is used to distinguish the primary computer from the SP. See ICMP Internet Control Message Protocol.
