Install the Oracle Storage 12 Gb/s SAS PCIe RAID HBA Card

Related Information
"Install the Oracle Storage 12 Gb/s SAS PCIe RAID HBA Card" on page 184
■
Install the Oracle Storage 12 Gb/s SAS PCIe RAID
HBA Card
1. Unpack the replacement Oracle Storage 12 Gb/s SAS PCIe RAID HBA card and
super capacitor, and place them on an antistatic mat.
2. Swivel the air baffle into the upright position and install the super capacitor
cable along the left sidewall of the chassis.
Install the super capacitor cable on top of the SAS cable bundle along the left sidewall of the
chassis. Otherwise, the SAS cable bundle will interfere with the air baffle.
3. Connect the super capacitor cable to the Oracle Storage 12 Gb/s SAS PCIe RAID
HBA, and then reconnect the SAS cables that you unplugged during the removal
procedure [1].
To ensure proper SAS cable connections, see
Cables" on page
184 Oracle Server X5-2L Service Manual • May 2015
171.
"Install SAS Storage Drive
