Remove an Internal USB Flash Drive

Caution -
flash drive or damage to the drive might occur. You must disconnect all power cables from the
system before performing these procedures.
This section covers the following procedures:
"Servicing the Oracle System Assistant USB Flash Drive" on page 122
■
"Remove an Internal USB Flash Drive" on page 122
■
"Install an Internal USB Flash Drive" on page 124
■
Related Information
"USB Ports" on page 240
■
Servicing the Oracle System Assistant USB Flash
Drive
If the Oracle System Assistant software is corrupted on the USB flash drive, you should try to
repair it before replacing the USB flash drive.
Oracle System Assistant uses a specially formated USB flash drive. Do not replace the Oracle
System Assistant flash drive with a standard flash drive. If the Oracle System Assistant USB
flash drive fails and it cannot be repaired by reloading the Oracle System Assistant software,
contact Oracle Services and request a service call to have Oracle System Assistant USB flash
drive replaced.
Note -
USB flash drive in the bottom USB slot.
For instructions for troubleshooting and repairing Oracle System Assistant, refer to the Oracle
System Assistant troubleshooting information in the Oracle X5 Series Servers Administration
Guide at http://www.oracle.com/goto/x86AdminDiag/docs.
Remove an Internal USB Flash Drive
The server can be equipped with up to two internal USB Flash drives.
1. Prepare the server for service.
122 Oracle Server X5-2L Service Manual • May 2015
Ensure that all power is removed from the server before removing or installing a
If your server is configured with Oracle System Assistant software, it is located on the
