Install a Fan Module
Related Information
"Install a Fan Module" on page 92
■
Install a Fan Module
1.
Remove the replacement fan module from its packaging, and place it on an
antistatic mat.
With the top cover fan assembly door open, install the replacement fan module
2.
into the server [1].
The fan modules are keyed to ensure that they are installed in the correct orientation.
FIGURE 22
92
Oracle Server X5-2L Service Manual • May 2015
Installing a Fan Module
