Servicing NVMe Cables (FRU)

■
b. Lower the air baffle to the installed position.
Install the fan modules and close the fan assembly door.
c.
See
d. Install the server top cover.
See
e. Return the server to the normal rack position.
See
Reconnect the power cords to the power supplies, and power on the server.
f.
See
Server" on page
Related Information
"Install the Oracle Storage 12 Gb/s SAS PCIe RAID HBA Card" on page 184
■
"Remove SAS Storage Drive Cables" on page 168
■
Servicing NVMe Cables (FRU)
Caution -
personnel.
Caution -
To avoid personal injury or damage to the server, you must disconnect power cords before
servicing the cables.
This section covers the following procedures:
"Remove NVMe Cables" on page 175
■
"Install NVMe Cables" on page 177
■
174 Oracle Server X5-2L Service Manual • May 2015
If your server is configured with eight 2.5-inch storage drives, install the
server's disk cage cover.
See "Install the Disk Cage Cover" on page
"Install a Fan Module" on page
"Install the Server Top Cover" on page
"Return the Server to the Normal Rack Position" on page
"Reconnect Power and Data Cables" on page 233
233. Verify that the power supply AC OK LED is lit.
NVMe cables should be removed and replaced only by authorized Oracle Service
The system supplies power to the cables even when the server is powered off.
229.
92.
226.
and "Power On the
231.
