6. Depending on the components that you are servicing, either extend the server to
the maintenance position, or remove the server from the rack.
Related Information
"Rear Panel Components and Cable Connections" on page 18
■
"Powering Down the Server" on page 55
■
"Extend the Server to the Maintenance Position" on page 61
■
"Remove the Server From the Rack" on page 63
■
"Reconnect Power and Data Cables" on page 233
■

Extend the Server to the Maintenance Position

The following components can be serviced with the server in the maintenance position:
Storage drives
■
Fan modules
■
Power supplies
■
DVD drive
■
DDR4 DIMMs
■
PCIe cards and cables
■
SAS cables
■
NVMe cables
■
Internal USB drives
■
System battery
■
Processors
■
Disk backplanes
■
Front indicator modules
■
Motherboard
■
If the server is installed in a rack with extendable slide-rails, use this procedure to extend the
server to the maintenance position.
1. To prevent the rack from tipping forward when the server is extended, extend all
rack anti-tilt devices.
For instructions for stabilizing the rack, refer to
Server X5-2L Installation Guide
2. Verify that no cables will be damaged or will interfere when the server is
extended.
Extend the Server to the Maintenance Position
"Stabilize the Rack for Installation" in "Oracle
".
