Oracle X5-2L Service Manual page 179

System Disk
Configuration
Eight storage drive
Twenty-four storage drives
4. Return the server to operation.
a. Depending on your server's storage drive configuration, do one of the
following:
■ If your server is configured with twenty-four 2.5-inch storage drives,
install the server's front fan assembly door cover.
See "Install the Fan Assembly Door" on page
If your server is configured with eight 2.5-inch storage drives, install the
■
server's disk cage cover.
See "Install the Disk Cage Cover" on page
b. Lower the air baffle to the installed position.
Install the fan modules and close the fan assembly door.
c.
See "Install a Fan Module" on page
d. Install the server top cover.
See "Install the Server Top Cover" on page
e. Return the server to the normal rack position.
See "Return the Server to the Normal Rack Position" on page
Reconnect the power cords to the power supplies, and power on the server.
f.
See "Reconnect Power and Data Cables" on page 233
Server" on page
Related Information
"Remove NVMe Cables" on page 175
■
Disk Backplane Oracle PCIe NVMe
Cable Connector Switch Card Port
Cable Connector
A 2,3
B 0,1
A 2,3
B 0,1
92.
233. Verify that the power supply AC OK LED is lit.
Cable Part
Number
7089783
7089784
228.
229.
226.
231.
and "Power On the
Install NVMe Cables
Servicing FRUs 179
