c. Lower the processor into the tool and press the tool release lever to release
the center button and engage the processor [3].
An audible click indicates that the processor is locked into place.
d. Properly position the tool over the processor socket and lower it into place
[4].
To properly position the tool in the processor socket, rotate the tool until the green triangle
on the side of the tool is facing the front of the server and it is over the left side of the
processor socket (when viewing the server from the front) and lower the tool into the
processor socket.
e. Press the center button on the tool down to release the processor so that it
is installed in the socket [5].
f. Remove the processor removal and replacement tool [6].
The following figure shows the green color-coded processor removal and
Caution -
replacement tool. If you are installing a processor with 12 or more cores, you must use the pink
color-coded processor removal and replacement tool. For information on how to select the
correct processor removal and replacement tool, see
and Replacement Tool" on page
"Selecting the Correct Processor Removal
130.
Install a Processor
Servicing FRUs 141
