Component Name (Oracle ILOM CLI
Targets)
/SYS/MB/P[0-x]/D[0-11]
/SYS/MB/P[0-x]/D[0-11]/PRSNT
/SYS/MB/P[0-x]/D[0-11]/SERVICE
Related Information
"System Chassis Components" on page 295
■
"Cooling Unit Components" on page 296
■
"Disk Backplane Components" on page 297
■
"Power Unit Components" on page 299
■
"Processor Components" on page 300
■
"System Board Components" on page 301
■
"System Firmware Components" on page 302
■
"Hard Disk Drive Components" on page 303
■

Power Unit Components

The following table lists the power unit components.
Component Name (Oracle ILOM CLI
Targets)
/SYS/PS[0-1]
/SYS/PS[0-1]/PRSNT
/SYS/PS[0-1]/STATE
IPMI Type Description
FRU Host CPU DIMM
FRU
Discrete Host CPU DIMM is
sensor present.
Indicator Host CPU DIMM
Service Required
LED
IPMI Type Description
FRU Power supply FRU
Discrete sensor Power supply is
present
Discrete sensor Multistate, power
supply sensor type,
per IPMI
Monitoring Components and Identifying SNMP Messages
Monitoring System Components
Values (if applicable)
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
Color: Amber
Location: Mainboard
Off: Normal
On: DIMM was diagnosed as
faulty.
Values (if applicable)
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
Presence detected
Failure detected
Predictive failure
Power supply input lost
Power supply input lost or
out-of-range
