Oracle X5-2L Service Manual page 280

BIOS Advanced Menu Selections
Setup Options
Active Mgmt Port
Commit
IPv4 Configuration
Channel Number (R/O)
Current IPv4 IP Assignment in
BMC (R/O)
Current IPv4 address in BMC
(R/O)
Current IPv4 MAC Address in
BMC (R/O)
Current IPv4 Subnet Mask in
BMC (R/O)
Current IPv4 Default Gateway
in BMC
Refresh
IPv4 IP Assignment
IPv4 Address
IPv4 Subnet Mask
IPv4 Default Gateway
Commit
IPv6 Configuration
280 Oracle Server X5-2L Service Manual • May 2015
Options
NET MGT/NET0/NET1/NET2/
NET3
NA
NA
Static/Dynamic
NA
NA
NA
NA
Static/Dynamic
NA
NA
NA
Defaults
NET MGT
NA
NA
1
Static
NA
NA
NA
NA
Static
NA
NA
NA
Description
information from the service
processor.
Use to change the currently
active network management
port.
Commit the current BMC
network LAN information.
Current configuration of the
IPv4 settings is displayed.
Current channel number is
displayed.
Set the IPV4 IP assignment to
Static or Dynamic. This setting
determines whether the service
processor is assigned a static
IPv4 address or assigned a
dynamic IPv4 address using
Dynamic Host Control Protocol
(DHCP).
Displays the current IPv4
address in the BMC.
If IPv4 Assignment is set to
Static, set the IPv4 address for
the service processor.
Example: 172.31.255.255
If the IPv4 Assignment is set to
Static, set the IPv4 subnet mask.
Example: 255.255.255.0
If the IPv4 Assignment is set
to Static, set the IPv4 default
gateway
Example: 172.31.255.255
Refresh the current BMC LAN
information.
Current IPv4 assignment.
If set, current IPv4 address is
displayed.
If set, current IPv4 Subnet Mask
is displayed.
If set, current IPv4 Default
Gateway is displayed.
Commit the current BMC LAN
information.
Current configuration of the
IPv6 settings is displayed.
