Remove the Storage Drive Backplane for Rear-Mounted Storage Drives

Note -
of the disk backplane is programmed by Oracle ILOM to contain the same KIP as the other
quorum member components. If you have removed other quorum member components,
you might need to manually program the product serial number (PSN) into the new disk
backplane. For more information, refer to
Update" on page
Related Information
"Remove the Storage Drive Backplane for Twenty-Four Drive Systems" on page 158
■
Remove the Storage Drive Backplane for Rear-
Mounted Storage Drives
1. Prepare the server for service.
a. Power off the server and disconnect the power cords from the power
supplies.
See
Extend the server into the maintenance position.
b.
See
c. Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See
d. Remove the server top cover.
See
Swivel the air baffle into the upright position to allow access to the storage
e.
drive backplane.
2. Pull each rear-mounted storage drive out far enough to disengage if from the
disk backplane.
See "Remove a Rear Storage Drive" on page
162 Oracle Server X5-2L Service Manual • May 2015
IMPORTANT: When the disk backplane is replaced, the key identity properties (KIP)
53.
"Powering Down the Server" on page
"Extend the Server to the Maintenance Position" on page
"Take Antistatic Measures" on page
"Remove the Server Top Cover" on page
"FRU Key Identity Properties (KIP) Automated
55.
64.
64.
86.
61.
