Oracle X5-2L Service Manual page 147

a. Power off the server and disconnect the power cords from the power
supplies.
See "Powering Down the Server" on page
b. Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See "Take Antistatic Measures" on page
c. Extend the server into the maintenance position.
See "Extend the Server to the Maintenance Position" on page
Remove the disk cage cover.
d.
See "Remove the Disk Cage Cover From the Server" on page
e. If necessary, remove the fan modules from the server.
See "Remove a Fan Module" on page
Pull each storage drive out far enough to disengage if from the disk backplane.
2.
See "Remove an HDD or SSD Storage Drive" on page
It is not necessary to completely remove the storage drives from the server; simply
Note -
pull them out far enough to disengage them from the disk backplane. If you do remove the
storage drives from the server, record their locations so that you can reinstall them in the same
locations.
3. Disconnect the cables from the storage drive backplane.
Disconnect the two SAS cables from the storage drive backplane to the
a.
Oracle Storage 12 Gb/s SAS PCIe RAID HBA [1].
Note the cable connections in order to ease proper reconnection of the cables.
Remove the Storage Drive Backplane for Eight-Drive Systems
55.
64.
89.
73.
61.
67.
Servicing FRUs 147
