Message body is the XML body and contains the "dial-tone-pattern" set to "special-
condition-tone" (<ss:dial-tone-pattern>special-condition-tone</ss:dial-tone-pattern>),
which is the special tone indication.
To cancel the special dial tone and playing the regular dial tone, the received SIP NOTIFY
message must contain the following headers:

From and To: contain the same information, indicating the specific endpoint

Event: ua-profile

Content-Type: "application/simservs+xml"

Message body is the XML body containing the "dial-tone-pattern" set to "standard-
condition-tone" (<ss:dial-tone-pattern>standard-condition-tone</ss:dial-tone-pattern>),
which is the regular dial tone indication.
Therefore, the special dial tone is valid until another SIP NOTIFY is received that instructs
otherwise (as described above).
Note: if the MWI service is active, the MWI dial tone overrides this special Call
Forward dial tone.
26.6.3 Call Forward Reminder Dial Tone (Off-Hook) upon Spanish SIP
Alert-Info
The device plays a special dial tone to FXS phones in off-hook state that are activated with
the call forwarding service. The special dial tone is used as a result of the device receiving
a SIP NOTIFY message from a third-party softswitch providing the call forwarding service
with the following SIP Alert-Info header:
Alert-Info: <http://127.0.0.1/Tono-Espec-Invitacion>;lpi-
aviso=Desvio-Inmediato
This special tone is a stutter dial tone (Tone Type = 15), as defined in the CPT file.
The FXS phone user, connected to the device, activates the call forwarding service by
dialing a special number (e.g., *21*xxxxx) and as a result, the device sends a regular SIP
INVITE message to the softswitch. The softswitch later notifies of the activation of the
forwarding service by sending an unsolicited NOTIFY message with the Alert-Info header,
as mentioned above.
When the call forwarding service is de-activated, for example, by dialing #21# and sending
an INVITE with this number, the softswitch sends another SIP NOTIFY message with the
following Alert-Info header:
Alert-Info: <http://127.0.0.1/ Tono-Normal-Invitacion>; Aviso =
Desvi‫-ף‬Inmediato
From this point on, the device plays a normal dial tone to the FXS phone when it goes off-
hook.
26.6.4 B RI Call Forwarding
4 0 5 B
The device supports call forwarding (CF) services initiated by ISDN Basic BRI phones
connected to it. Upon receipt of an ISDN Facility message for call forward from the BRI
phone, the device sends a SIP INVITE to the softswitch with a user-defined code in the SIP
To header, representing the reason for the call forward.
The codes for the call forward can be defined using the following parameters:

SuppServCodeCFU - Call Forward Unconditional

SuppServCodeCFUDeact - Call Forward Unconditional Deactivation
