Set value Function
4 Jogging operation
5 Inverter fault
Frequency degree test
6
FDT1
Frequency degree test
7
FDT2
8 Frequency arrival
9 Zero speed running
Upper limit frequency
10
arrival
Lower limit frequency
11
arrival
12 Ready for operation
13 Pre-excitation
14 Overload pre-alarm
15 Underload pre-alarm
Completion of simple
16
PLC step
Completion of simple
17
PLC cycle
18 Reserved
19 Reserved
20 External fault valid
21 Reserved
22 Running time arrival
MODBUS
23 communication virtual
terminal output
POROFIBUS/CANopen
24 communication virtual
terminal output
Ethernet communication
25
virtual terminal output
26~28 Reserved
29 Motor overheat
When the inverter jogs, the output is valid.
When there is an inverter fault, the frequency output is valid.
Refer to Function code P08.32 and P08.33 for detailed
information.
Refer to Function code P08.34 and P08.35 for detailed
information.
Refer to Function code P08.36 for detailed information.
The output is valid when both the output frequency and
frequency reference of the inverter are equal to zero.
The output is valid when the running frequency reaches the
upper limit.
The output is valid when the running frequency reaches the lower
limit.
The output is valid when the power of the primary loop and
control loop is set up, and the inverter is ready for operation
without carrying out protection functions.
The output is valid at pre-excitation.
The output is valid after the inverter exceeds the pre-alarm time
on basis of the overload pre-alarm point. Refer to the function
codes P11.08~P11.10 for specific information.
The output is valid after the inverter exceeds the pre-alarm time
on basis of the underload pre-alarm point. Refer to the function
codes P11.11~P11.12 for specific information.
The output is valid after the simple PLC current step is
completed.
The output is valid after one simple PLC cycle is completed.
The output is valid when the external fault (EF) appears.
The output is valid after the accumulated running time of the
inverter exceeds the time set in P08.27.
Output corresponding signals according to MODBUS set values,
1 for ON signal and 0 for OFF signal.
Output corresponding
CANopen set values, 1 for ON signal and 0 for OFF signal.
Output corresponding signals according to Ethernet set values, 1
for ON signal and 0 for OFF signal.
The output is valid when the temperature of the motor is larger
