Function
Name
code
Output torque actual
6
value
Output power actual
7
value
Running rotating
8
speed
Running linear speed (*1, m/s)
9
Ramp reference
10
frequency
fault code
11
12 AI1 value
AI2 value
13
AI3 value
14
PULSE frequency
15
Input state of
16
terminals
Output state of
17
terminals
18 PID reference
PID feedback
19
Motor rated torque
20
Function
Name
code
Temporary variable 1
P15.24
for PZD sending
The function code is use as the temporary variable when PZD sends data.
The function code P15.24 is enabled to write at any state.
Function
Name
code
Fault time of DP
P15.25 communication
overtime
When the function code is set to 0.0s, the fault time of communication timeout will be invalid.
When the function code is set to non-zero (actual value, unit: second) and the interval between the
current and next communication exceeds the communication timeout, the system will alarm DP
communication fault (E-dP).
Function
Name
code
Fault time of CANopen
P15.26
communication timeout
When the function code=0.0s, the communication timeout fault will be invalid.
When the function code=non-zero and the interval between the current and next communication exceeds
the communication timeout, the system will alarm communication fault (E-CAN). Generally, set the
(*10, %)
(*10, %)
(*1, RPM)
(*100, V)
(*100, V)
(*100, V)
(*100, kHz)
(*100, %)
(*100, %)
Detailed parameter description
0~65535
Detailed parameter description
0.0: Invalid
0.1~60.0s
Detailed parameter description
0.0 (invalid)
0.1~60.0s
