Goodrive3000 series medium voltage inverters
Items
temperature 40℃
RH 5~95%
The inverter should be installed in a place free of dust, direct sunshine, flammable
Atmosphere
gasses, oil pollution, steam and vibration.
Below 1000m. Derating is required over 1000m. See Table 3.3 Altitude Derating
Altitude
Table for the specific derating factor
Vibration 2~9Hz displacement 3mm; 9~20Hz acceleration 9.8m/s
amplitude 2m/s
Altitude
＜1000m
1500~2000m
2500~3000m

3.3 Terminals of the main circuit

Goodrive3000 series product is multiple-inverter product and its terminals of main circuit are decrypted as
below:
Sign
R, S, T
U, V, W
BR1, BR2
DC+, DC-
PE
2
; 55~200Hz acceleration 1m/s
Table 3-3 Altitude Derating Table
Derating factor
1.0
0.95
0.88
Table 3-4 Terminals of the main circuit
3-phase AC input
3-phase AC output
External braking resistor terminal
DC bus output
Grounding terminal
Specifications
2
Altitude
1000~1500m
2000~2500m
3000~3500m
Description
-12-
Installation guidelines
2
; 20~55Hz acceleration
Derating factor
0.97
0.91
0.8
