INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 115

Goodrive3000 series medium voltage inverters
Function
Name
code
Set the control functions of the keypad.
Function
Name
code
Integral ratio of the
P08.43
keypad
potentiometer
UP/DOWN terminal
P08.44
control
Set the control functions of UP/DOWN terminals.
Function
Name
code
UP terminal
P08.45 frequency changing
ratio
DOWN terminal
P08.46 frequency changing
ratio
Set the frequency changing ratio of UP/DOWN terminals.
Detailed instruction of parameters
after receiving the stop command
LED thousands: ∧/∨ and digital
potentiometer integral function
0: Effective integral function
1: Ineffective integral function
Detailed instruction of parameters
0.01~10.00s
0x000~0x221
LED ones: Frequency control
selection
0: UP/DOWN terminal setting
effective
1: UP/DOWN terminal setting
ineffective
LED tens: Frequency control
selection
0: Only effective when P00.06=0 or
P00.07=0
1: Effective for all frequency setting
manners
2: Ineffective for multi-step speed
when multi-step speed has the
priority
LED hundreds: Action selection
during stopping
0: Effective setting
1: Effective during running, cleared
after stopping
2: Effective during running, cleared
after receiving the stop command
Detailed instruction of parameters
0.01~50.00s
0.01~50.00s
-114-
Goodrive3000 series converter
Default
Setting range
value
Default
Setting range
value
0.01~10.00 0.10s
000~221 0x000
Default
Setting range
value
0.01~50.00 0.50s
0.01~50.00 0.50s
