Goodrive3000 series medium voltage inverters
Function
Name
code
Parameter selection
P07.06
2 at running state
The parameter of Goodrive3000 series inverters at running state determined by P7.06 is the 16-bit binary
figure. If one bit of the figure is 1, the corresponding parameter of the bit can be checked
through >>/SHIFT at running state. If the bit is 0, the corresponding parameter will not be displayed.
When setting the function codes of P07.05 and P07.06, shift 2-bit into 16-bit and then input it into the
function code.
Note: AI3 and HDI need to use extension cards.
BIT15
PLC and
current step
in multi-step
P07.05
speed
BIT7
Output
torque
BIT15
Reserved Reserved Reserved
BIT7
P07.06
Reserved frequency
reference
Detailed instruction of parameters
BIT12: Torque set value(% on)
BIT13: Pulse count value
BIT14: Reserved
BIT15: PLC and current step in
multi-step speed
BIT0: AI1 value (V on)
BIT1: AI2 value (V on)
BIT2: AI3 value (V on)
BIT3: HDI frequency
BIT4: Motor overload percentage (%
on)
BIT5: Inverter overload percentage
(% on)
BIT6: Ramp reference frequency (Hz
on)
BIT7: Reserved
BIT8: Reserved
BIT9~15: Reserved
BIT14 BIT13
Pulse
Length Torque set
count
value
value
BIT6 BIT5
Running
Output
rotating
power
speed
BIT16 BIT13
Reserved Reserved Reserved Reserved Reserved
BIT6 BIT5
Ramp Inverter
overload overload
percentage percentage
Goodrive3000 series converter
BIT12 BIT11 BIT10
Output Input
terminal terminal
value
state
BIT4 BIT3
Output Output
current voltage voltage
BIT12 BIT11 BIT10
BIT4 BIT3
Motor
HDI
AI3 value AI2 value
frequency
-104-
Default
Setting range
value
0x0000~0xFFFF 0x0000
BIT9 BIT8
PID PID
feedback reference
state
BIT2 BIT1 BIT0
Bus Set Running
frequency frequency
BIT9 BIT8
BIT2 BIT1 BIT0
AI1 value
