Goodrive3000 series medium voltage inverters
Function
Name
code
P12.18 PZD7 sending
P12.19 PZD8 sending
P12.20 PZD9 sending
P12.21 PZD10 sending
P12.22 PZD11 sending
P12.23 PZD12 sending
Temporary
P12.24 variable 1 of PZD
sending
Time of DP
P12.25 communication
overtime fault
P12.26 Reserved
P12.27 Reserved
P12.28 Reserved
P12.29 Reserved
P13 Group Ethernet communication
Ethernet
P13.00 communication
speed setting
P13.01 IP address 1
P13.02 IP address 2
P13.03 IP address 3
P13.04 IP address 4
P13.05 Subnet mask 1
P13.06 Subnet mask 2
P13.07 Subnet mask 3
P13.08 Subnet mask 4
P13.09 Gateway address 1
P13.10 Gateway address 2
P13.11 Gateway address 3
P13.12 Gateway address 4
P13.13 Reserved
P13.14 Reserved
Detailed parameter
description
current
5: Input power
6: Input power factor
7: Grid frequency value
8: Active current feedback
9: Reactive current feedback
10: Fault code
11:AI1
12:AI2
13:AI3
14: Input state
15: Output state
16: Running status word
17~20: Reserved
0~65535
0.0 (invalid), 0.1~60.0s
0: Self-adaptive
1: 100M full-duplex
2: 100M half-duplex
3: 10M full-duplex
4: 10M half-duplex
0~255
0~255
0~255
-61-
Goodrive3000 series PWM rectifier
Setting
Default Modify No.
range
0~20 0
0~20 0
0~20 0
0~20 0
0~20 0
0~20 0
0~65535 0
0.0~60.0s 0.0s
0~4 3
0~255 192
0~255 168
0~255 0
0~255 1
0~255 255
0~255 255
0~255 255
0~255 0
0~255 192
0~255 168
0~255 1
0~255 1
○
