INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 134

Goodrive3000 series medium voltage inverters
Function
Name
code
frequency
Electromotion torque
7
upper limit
Braking torque upper
8
limit
Virtual input terminal
9
command
Virtual output terminal
10
command
Voltage set value
11
12 AO output set value 1 Range (-1000~1000, 1000 corresponds to 100.0%)
AO output set value 2 Range (-1000~1000, 1000 corresponds to 100.0%)
13
Function
Name
code
PZD2 sending
P15.13
PZD3 sending
P15.14
PZD4 sending
P15.15
PZD5 sending
P15.16
PZD6 sending
P15.17
PZD7 sending
P15.18
PZD8 sending
P15.19
PZD9 sending
P15.20
PZD10 sending
P15.21
PZD11 sending
P15.22
PZD12 sending
P15.23
For the second PZD in PROFIBUS-DP communication and master communication (sending), see
detailed information as follows:
Function
Name
code
Invalid
0
Running frequency (*100, Hz)
1
2 Set frequency
3 Bus voltage
Output voltage
4
Output current
5
0~3000, 1000 corresponds to 100.0% of motor rated current
0~2000, 1000 corresponds to 100.0% of motor rated current
Range: 0x000~0x1FF
Range: 0x00~0x0F
Special for V/F separation, range (0~1000, 1000 corresponds to
100.0% of motor rated voltage)
Detailed parameter description
0: Invalid
1: Running frequency
2: Set frequency
3: Bus voltage
4: Output voltage
5: Output current
6: Output torque actual value
7: Output power actual value
8: Running rotating speed
9: Running linear speed
10: Ramp reference frequency
11: Fault code
12: AI1 value
13: AI2 value
14: AI3 value
15: PULSE frequency
16: Input state of terminals
17: Output state of terminals
18: PID reference
19: PID feedback
20: Motor rated torque
(*100, Hz)
(*10, V)
(*1, V)
(*10, A)
-133-
Goodrive3000 series converter
Illustration
Setting range
0~20
0~20
0~20
0~20
0~20
0~20
0~20
0~20
0~20
0~20
0~20
Illustration
Default
0
0
0
0
0
0
0
0
0
0
0
