Goodrive3000 series medium voltage inverters
P12 Group Motor 2 parameters
Function
Name
code
P12.00 Motor 2 type
Asynchronous motor
P12.01
2 rated power
Asynchronous motor
P12.02
2 rated frequency
Asynchronous motor
P12.03
2 rated speed
Asynchronous motor
P12.04
2 rated voltage
Asynchronous motor
P12.05
2 rated current
Asynchronous motor
P12.06
2 stator resistor
Asynchronous motor
P12.07
2 rotor resistor
Asynchronous motor
P12.08 2 leakage
inductance
Asynchronous motor
P12.09
2 mutual inductance
Asynchronous motor
P12.10
2 non-load current
Magnetic saturation
P12.11 coefficient 1 for the
iron core of AM 2
Magnetic saturation
P12.12 coefficient 2 for the
iron core of AM 2
Magnetic saturation
P12.13 coefficient 3 for the
iron core of AM 2
Magnetic saturation
P12.14 coefficient 4 for the
iron core of AM 2
Motor 2 overload
P12.26
protection
Motor 2 overload
P12.27
protection coefficient
Detailed parameter description
0: Asynchronous motor
1: Reserved
0.1~3000.0kW
0.01Hz~P00.03 (Max. frequency)
1~36000rpm
0~4000V
0.8~6000.0A
0.001~65.535Ω
0.001~65.535Ω
0.1~6553.5mH
0.1~6553.5mH
0.1~6553.5A
0.0~100.0%
0.0~100.0%
0.0~100.0%
0.0~100.0%
0: No protection
1: Common motor (with low speed
compensation)
2: Frequency conversion motor
(without low speed compensation)
20.0%~120.0%
-128-
Goodrive3000 series converter
Setting range Default
0~1
Depend
0.1~3000.0
on model
0.01~P00.03 50.00Hz
Depend
1~36000
on model
Depend
0~4000
on model
Depend
0.8~6000.0
on model
Depend
0.001~65.535Ω
on model
Depend
0.001~65.535Ω
on model
Depend
0.1~6553.5mH
on model
Depend
0.1~6553.5mH
on model
Depend
0.1~6553.5A
on model
0.0~100.0 80.0%
0.0~100.0 68.0%
0.0~100.0 57.0%
0.0~100.0 40.0%
0~2
20.0~120.0 100.0%
0
2
