INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 181

Goodrive3000 series medium voltage inverters
Function
Name
code
of motors
FDT1 electrical
level detection
P08.32
value
FDT1 retention
P08.33
detection value
FDT2 electrical
level detection
P08.34
value
FDT2 retention
P08.35
detection value
Frequency
arrival detection
P08.36
value
Energy braking
P08.37
enable
Threshold
voltage of
P08.38
energy braking
Running mode
P08.39
of cooling fan
Reserved
P08.40
Over modulation
P08.41
selection
Keypad data
P08.42
control
Detailed instruction of parameters
1: MODBUS communication shifting
2: PROFIBUS/CANopen
communication shifting
3: Ethernet communication shifting
4: Reserved
0.00~P00.03 (Max. frequency)
0.0~100.0% (FDT1 electrical level)
0.00~P00.03 (Max. frequency)
0.0~100.0% (FDT2 electrical level)
0.0~P00.03 (Max. frequency)
0: Disabled
1: Enabled
600.0~6000.0V
0: Normal running mode
1: The fan keeps running after power
on all the time.
0: Invalid
1: Valid
0x0000~0x1223
LED ones: Frequency enabling
selection
0: Both ∧/∨ and digital potentiometer
adjustments are effective.
1: Only ∧/∨ is effective.
2: Only digital potentiometer
adjustment is effective.
3: Neither ∧/∨ nor digital
potentiometer adjustments is
effective.
LED tens: Frequency control selection
0: Only effective when P00.06=0 or
P00.07=0
1: Effective for all frequency setting
manners
2: Ineffective for multi-step speed
when multi-step speed has the priority
LED hundreds: Action selection
during stopping
-180-
Goodrive3000 series converter
Default
Setting range
value
0.00~P00.03 50.00Hz
0.0~100.0 5.0%
0.00~P00.03 50.00Hz
0.0~100.0 5.0%
0.0~P00.03 0.00Hz
0~1 0
600.0~6000.0 1950.0V
0~1 0
0~1 1
0000~1223
0x0000
Modify No.
○
326.
○
327.
○
328.
○
329.
○
330.
○
331.
○
332.
○
333.
◎
334.
◎
335.
○
336.
