Goodrive3000 series medium voltage inverters
After the motor finishes the parameter autotuning normally, the set values of P02.06~P02.10 will
automatically update. These parameters are the fundamental parameters of high performance vector
control and directly influence control performance.
Function
Name
code
Magnetic saturation
P02.11 coefficient 1 for the
iron core of AM 1
Magnetic saturation
P02.12 coefficient 2 for the
iron core of AM 1
Magnetic saturation
P02.13 coefficient 3 for the
iron core of AM 1
Magnetic saturation
P02.14 coefficient 4 for the
iron core of AM 1
Function
Name
code
Motor 1 overload
P02.26
protection
0: No protection
1: Common motor (with low speed compensation): because the heat dissipation effect of the common
motor at low speed will be weakened, the corresponding electric heat protection will be adjusted properly.
The low speed compensation characteristic mentioned here means reducing the threshold of the
overload protection of the motor whose running frequency is below 30Hz.
2: Frequency conversion motor (without low speed compensation): because the heat dissipation effect of
the special motor for the inverter is not affected by the speed, there is no need to adjust the protection
value during low speed running.
Function
Name
code
Motor 1 overload
P02.27 protection
coefficient
Motor overload multiple M=lout/(In*K)
In: motor rated current, Iout: inverter output current, K: motor overload protection coefficient
The relation between motor overload time and protection coefficient is:
Protection
110%
coefficient
Overload
60min
time
Detailed instruction of parameters
0.0~100.0%
0.0~100.0%
0.0~100.0%
0.0~100.0%
Detailed instruction of parameters
0: No protection
1: Common motor (with low speed
compensation)
2: Frequency conversion motor
(without low speed compensation)
Detailed instruction of parameters
20.0%~120.0%
120% 130% 140%
30min 10min 5min
Goodrive3000 series converter
150% 160%
1min 45s
-75-
Default
Setting range
value
0.0~100.0 88.0%
0.0~100.0 68.0%
0.0~100.0 57.0%
0.0~100.0 40.0%
Default
Setting range
value
0~2 2
Default
Setting range
value
20.0~120.0 100.0%
180% 190% 200%
10s 3s 1s
