Goodrive3000 series medium voltage inverters
P12 Group PROFIBUS communication
Function
Name
code
P12.00 Module type
P12.01 Module address
The function code is used to identify the address of PWM rectifier.
Note: 0 is the broadcast address. If P12.01 is 0, then it can only receive and carry out the
broadcast command from upper PC, other than response.
Function
Name
code
P12.02 PZD2 receiving
P12.03 PZD3 receiving
P12.04 PZD4 receiving
P12.05 PZD5 receiving
P12.06 PZD6 receiving
P12.07 PZD7 receiving
P12.08 PZD8 receiving
P12.09 PZD9 receiving
P12.10 PZD10 receiving
P12.11 PZD11 receiving
P12.12 PZD12 receiving
Detailed description of the second PZD word of PROFIBUS-DP communication and master
communication:
Function
Name
code
0 Invalid
1 DC voltage setting
2 Reserved
3 Reserved
4 Reserved
5 AO output setting 1
6 AO output setting 2
7~13 Reserved
P12.02~P12.12 can be modified in any state.
Function
Name
code
P12.13 PZD2 sending
P12.14 PZD3 sending
P12.15 PZD4 sending
P12.16 PZD5 sending
P12.17 PZD6 sending
P12.18 PZD7 sending
P12.19 PZD8 sending
P12.20 PZD9 sending
Detailed parameter description
0: PROFIBUS
0~127
Detailed parameter description
0: Invalid
1: DC voltage setting
2~4: Reserved
5: AO output setting 1
6: AO output setting 2
7~13: Reserved
0~20000, unit 0.1V
-1000~1000, 1000 corresponds to 100.0%
-1000~1000, 1000 corresponds to 100.0%
Detailed parameter description
0: Invalid
1: DC voltage
2: DC voltage feedback
3: Input voltage valid
4: Valid value of the input current
5: Input power
6: Input power factor
7: Grid frequency value
-40-
Goodrive3000 series PWM rectifier
Setting range
0~1
0~127
Setting range
0~13
0~13
0~13
0~13
0~13
0~13
0~13
0~13
0~13
0~13
0~13
Description
Setting range
0~20
0~20
0~20
0~20
0~20
0~20
0~20
0~20
Default
0
2
Default
0
0
0
0
0
0
0
0
0
0
0
Default
0
0
0
0
0
0
0
0
