Goodrive3000 series medium voltage inverters
Function
Name
code
P12.21 PZD10 sending
P12.22 PZD11 sending
P12.23 PZD12 sending
Detailed description of the second PZD word of PROFIBUS-DP communication and master
communication:
Function
Name
code
0 Invalid
1 DC voltage
2 DC voltage feedback
3 Input voltage valid
Valid value of the input
4
current
5 Input power
6 Input power factor
7 Grid frequency value
8 Active current feedback 100% corresponds to the rated current of the rectifier
Reactive current
9
feedback
10 Fault code
11 AI1
12 AI2
13 AI3
14 Input state
15 Output state
16 Running status word
17~20 Reserved
P12.13~P12.23 can be modified in any state.
Function
Name
code
Temporary variable
P12.24
1 of PZD sending
The function code is used as temporary variable for PZD sending.
P12.24 can be written in any state.
Detailed parameter description
8: Active current feedback
9: Reactive current feedback
10: Fault code
11:AI1
12:AI2
13:AI3
14: Input state
15: Output state
16: Running status word
17~20: Reserved
*10, V
*10, V
*10, V
*10, A
*10, kW
*100
*10, Hz
100% corresponds to the rated current of the rectifier
*100, V
*100, V
*100, V
Detailed parameter description
0~65535
-41-
Goodrive3000 series PWM rectifier
Setting range
0~20
0~20
0~20
Description
Setting range
0~65535
Default
0
0
0
Default
0
