INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 102

Goodrive3000 series medium voltage inverters
Function
Name
code
Corresponding AO2
P06.27
output to lower limit -10.00V~10.00V
Upper limit of AO2
P06.28
output
Corresponding AO2
P06.29
output to upper limit -10.00V~10.00V
AO2 output filter
P06.30
time
Lower limit of AO3
P06.31
output
Corresponding AO3
P06.32 output frequency to
lower limit
Upper limit of AO3
P06.33
output
Corresponding AO3
P06.34 output frequency to
upper limit
AO3 output filter
P06.35
time
Lower limit of HDO
P06.36
output
Corresponding HDO
output frequency to
P06.37
lower limit
Upper limit of HDO
P06.38
output
Corresponding HDO
output frequency to
P06.39
upper limit
HDO output filter
P06.40
time
The function code defines the relationship between the output value and its corresponding analog output.
If the output value exceeds the set minimum or maximum output value, calculate it as the lower limit or
upper limit of output.
When the analog output is current output, the current of 1mA is equivalent to the voltage of 0.5V.
In different cases, the corresponding analog output to 100% of output value is different. See specific
information in each section.
Detailed instruction of parameters
P06.26~100.0%
0.000s~10.000s
-100.0%~P06.33
-10.00V~10.00V
P06.31~100.0%
-10.00V~10.00V
0.000s~10.000s
-100.0%~P06.38
0.00~50.00kHz
P06.36~100.0%
0.00~50.00kHz
0.000s~10.000s
Corresponding
setting
100%
-10V (-20mA )
0
AO1 AO2
-100%
-101-
Goodrive3000 series converter
Setting range
-10.00~10.00
P06.26~100.0
-10.00~10.00
0.000~10.000
-100.0~P06.33
-10.00~10.00
P06.31~100.0
-10.00~10.00
0.000~10.000
-100.0%~P06.38
0.00~50.00
P06.36~100.0
0.00~50.00
0.000~10.000
AO
10V
(20mA)
Default
value
0.00V
100.0%
10.00V
0.000s
0.0%
0.00V
100.0%
10.00V
0.000s
0.00%
0.0kHz
100.0%
50.00kHz
0.000s
