Goodrive3000 series medium voltage inverters

Chapter 9 Peripheral options and parts

9.1 Optional card

The optional cards of Goodrive3000 series inverters are shown below:
Table 9-1 Optional cards of Goodrive3000 series inverters
Name
Comprehensive
ASY01_PB12301_TF4
extension card
5V incremental
encoder PG card
12V encoder PG
card
24V encoder PG
card
Rotary encoder PG
card
Communication
extension card
9.1.1 Operation instruction and wiring of comprehensive extension card
9.1.1.1 Instruction of terminals
RO3A RO3B RO3C
Terminal
Type
No.
+10V
24V
Power supply
PW
Analog input AI3
Model
Can extend analog input/output, switch input/output
and CAN communication
5V incremental ABZ encoder, support differential
EC-PG101-05
input, Max. frequency 200kHz
12V incremental ABZ encoder, support differential,
EC-PG101-12
OC and push-pull input, Max. frequency 100kHz
24V incremental ABZ encoder, support differential,
EC-PG101-24
OC and push-pull input, Max. frequency 100kHz
Rotary transformer encoder, support pulse/direction
EC-PG104-00 differential input, Max. frequency 500kHz, 5V
differential frequency division output
EC-TX103 PROFIBUS and Ethernet communication interface
EC-TX105 CANopen and Ethernet communication interface
S7 S8 HDI
+24V PW COM
Fig 9-1 Terminals of comprehensive extension card
Table 9-2 Instruction of terminals
Terminal
name
+10V GND as reference;
reference Set point: 10.5V, Max. output current: 100mA, output
power supply shortcircuit protection, precision: 1%
24V power COM as reference;
supply Provide working power supply inside
COM as reference;
External power Provide working power supply of digital input/output
supply from outside to inside
Input voltage range: DC12~30V
GND as reference;
1. Input range: 0~10V/0~20mA, 12bit resolution, error
Analog input 3
± 1%, 25℃
2. Voltage or current input is set by J13
Description
GND AI3 +10V
CANL CANHCOMX
CME HDO AO3 PTA
Description
-218-
Peripheral options and parts
Remark
9.1.1
9.1.2
9.1.3
9.1.4
PTB PTC
