Goodrive3000 series medium voltage inverters
Function
Name
code
P06.17 AO1 output
P06.18 AO2 output
P06.19 AO3 output
HDO pulse
P06.20
output
Lower limit of
P06.21
AO1 output
Corresponding
AO1 output to
P06.22
lower limit
Upper limit of
P06.23
AO1 output
Corresponding
AO1 output to
P06.24
upper limit
AO1 output filter
P06.25
time
Lower limit of
P06.26
AO2 output
Detailed instruction of parameters
0: Running frequency
1: Set frequency
2: Ramp reference frequency
3: Running rotating speed
4: Output current (Relative to inverter)
5: Output current (Relative to motor)
6: Output voltage
7: Output power
8: Set torque value
9: Output torque
10: AI1 input value
11: AI2 input value
12: AI3 input value
13: HDI pulse frequency input value
14: MODBUS communication set
value 1
15: MODBUS communication set
value 2
16: PROFIBUS/CANopen
communication set value 1
17: PROFIBUS/CANopen
communication set value 2
18: Ethernet communication set value
1
19: Ethernet communication set value
2
20: PID reference
21: PID feedback
22: Torque current (Relative to motor
rated current)
23: Ramp reference frequency (with
sign)
24~30: Reserved
-100.0%~P06.23
-10.00V~10.00V
P06.21~100.0%
-10.00V~10.00V
0.000s~10.000s
-100.0%~P06.28
-171-
Goodrive3000 series converter
Default
Setting range
value
0~30 0
0~30 0
0~30 0
0~30 0
-100.0~P06.23 0.0%
-10.00~10.00 0.00V
P06.21~100.0 100.0%
-10.00~10.00 10.00V
0.000~10.000 0.000s
-100.0~P06.28 0.0%
Modify No.
○
214.
○
215.
○
216.
○
217.
○
218.
○
219.
○
220.
○
221.
○
222.
