INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 124

Goodrive3000 series medium voltage inverters
After selecting corresponding ACC/DEC time, users have to convert the combined 16 binary bit into the
decimal bit and set the related function codes.
Function
Name
code
P10.36 PLC restart
Set the restart manners of PLC.
0: Restart from the first step: the inverter will restart from the first step after stop (caused by the stop
command, faults or power loss).
1: Continue to run from the stop frequency: the inverter will record the running time at current step after
stop (caused by the stop command or faults), automatically enter into the step and then remain to run at
the frequency defined by the step.
Function
Name
code
P10.37 Multi-step time unit
Set the time unit.
0: Second: the running time of all steps is counted by second.
1: Minute: the running time of all steps is counted by minute.
Detailed instruction of parameters
0: Restart from the first step
1: Continue to run from the stop
frequency
Detailed instruction of parameters
0: Second
1: Minute
-123-
Goodrive3000 series converter
Default
Setting range
value
0~1
Default
Setting range
value
0~1
0
0
