P11 Group Protective parameters
Function
Name
code
Phase loss
P11.00
protection
Enable the function of phase loss protection.
Function
Name
code
Instantaneous
power loss
P11.01
frequency
decreasing
Enable instantaneous power loss frequency-decreasing function.
Function
Name
code
Frequency
decreasing velocity
P11.02
of instantaneous
power loss
After the power loss of the grid, when the bus voltage drops to the instantaneous power loss
frequency-decreasing point, the inverter begins to decrease the running frequency according to the
decreasing velocity and make the motor in power generation again. The feedback power can maintain
the bus voltage to ensure the continuous running of the inverter until the recovery of power.
Note:
1. Adjusting the parameter properly can prevent the stop caused by the inverter protection during
shifting the grid.
2. The function can be enabled only by disabling input phase loss protection.
Function
Name
code
Overvoltage speed
P11.03
loss protection
Enable the function of overvoltage speed loss protection.
Detailed instruction of parameters
0x00~0x11
LED ones:
0: Disable input phase loss protection
1: Enable input phase loss protection
LED tens:
0: Disable output phase loss
protection
1: Enable output phase loss
protection
Detailed instruction of parameters
0: Disabled
1: Enabled
Detailed instruction of parameters
0.00Hz/s~P00.03Hz/s (Max.
frequency)
Voltage degree
Frequency-decreasing point
of instantaneous power loss
Detailed instruction of parameters
0: Disabled
1: Enabled
-124-
Goodrive3000 series converter
Setting range
00~11
Setting range
0~1
Setting range
0.00~P00.03
1140V
1350V
Setting range
0~1
Default
value
11
Default
value
0
Default
value
10.00Hz/s
Default
value
0
