Goodrive3000 series medium voltage inverters
Function
Name
code
integral
coefficient I
Torque setting
P03.11
method
Keypad setting
P03.12
torque
Torque given
P03.13
filter time
Torque control
forward rotation
upper-limit
P03.14
frequency
setting source
selection
Torque control
reverse rotation
upper-limit
P03.15
frequency
setting source
selection
Keypad defined
value of torque
control forward
P03.16
rotation
upper-limit
frequency
Keypad defined
value of torque
control reverse
P03.17
rotation
upper-limit
frequency
P03.18 Electromotion 0: Keypad setting (P03.20 sets
Detailed instruction of parameters
0: Invalid torque control
1: Keypad setting (P03.12)
2: AI1 setting
3: AI2 setting
4: AI3 setting
5: HDI pulse frequency setting
6: Multi-step setting
7: MODBUS communication setting
8: PROFIBUS/CANopen
communication setting
9: Ethernet communication setting
10: Reserved
-300.0%~300.0% (Motor rated
current)
0.000~10.000s
0: Keypad setting (P03.16 sets
P03.14 and P03.17 sets P03.15)
1: AI1 setting
2: AI2 setting
3: AI3 setting
4: HDI pulse frequency setting
5: Multi-step setting
6: MODBUS communication setting
7: PROFIBUS/CANopen
communication setting
8: Ethernet communication setting
9: Reserved
0.00Hz~P00.03
0.00Hz~P00.03
-161-
Goodrive3000 series converter
Default
Setting range
value
0~10 0
-300.0~300.0 50.0%
0.000~10.000s 0.100s
0~9 0
0~9 0
50.00
0.00~P00.03
Hz
0.00~P00.03 50.00Hz
0~8 0
Modify No.
○
86.
○
87.
○
88.
○
89.
○
90.
○
91.
○
92.
○
93.
