INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 175

Goodrive3000 series medium voltage inverters
Function
Name
code
The parameter
P07.07
at stop state
Frequency
P07.08
coefficient
Rotating speed
P07.09
coefficient
Linear speed
P07.10
coefficient
Rectifier bridge
P07.11 module
temperature
Converter
P07.12 module
temperature
Software version
P07.13
of control board
Local
P07.14 accumulative
running time
High bit of power
P07.15
consumption
Detailed instruction of parameters
BIT4: Motor overload percentage (%
on)
BIT5: Inverter overload percentage (%
on)
BIT6: Ramp reference frequency (Hz
on)
BIT7: Reserved
BIT8: Reserved
BIT9~15: Reserved
BIT0: Set frequency (Hz on, frequency
flickering slowly)
BIT1: Bus voltage (V on)
BIT2: Input terminal state
BIT3: Output terminal state
BIT4: PID reference (% flickering)
BIT5: PID feedback (% on)
BIT6: Torque set value (% on)
BIT7: AI1 value (V on)
BIT8: AI2 value (V on)
BIT9: AI3 value (V on)
BIT10: HDI frequency
BIT11: PLC and current step in
multi-step speed
BIT12: Reserved
BIT13: Reserved
BIT14~BIT15: Reserved
0.01~10.00
0.1~999.9%
0.1~999.9%
0.0~100.0℃
0.0~100.0℃
1.00~655.35
0~65535h
0~65535° (*1000)
-174-
Goodrive3000 series converter
Default
Setting range
value
0000~FFFF 0x00FF
0.01~10.00 1.00
0.1~999.9% 100.0%
0.1~999.9% 1.0%
Modify No.
○
244.
○
245.
○
246.
○
247.
●
248.
●
249.
●
250.
●
251.
●
252.
