INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 33

Goodrive3000 series medium voltage inverters
P07 Group Human-machine interface
Function
Name
code
P07.00 User password
The password protection function will be valid when set to be any non-zero data.
00000: user's password set before will be cleared and the password protection function will be disabled.
After the password has been set and becomes valid, the user can not access menu if the user's
password is not correct. Only when a correct user's password is input, the user can see and modify the
parameters. Please keep user's password in mind.
Press PRG/ESC again to the function code editing state, "0.0.0.0.0" will be displayed. Unless using the
correct password, the operators cannot enter it.
Note: The password will be cleared if the default value is restored.
Function
Name
code
P07.01 Parameters copy
Set the way of parameter copy.
Note: When upload or download operation completes, the parameter will be set to 0 automatically.
Function
Name
code
QUICK/JOG
P07.02
function selection
Set the function of QUICK/JOG.
Function
Name
code
STOP/RST
P07.04
function selection
The function of STOP/RST is always valid.
Function
Name
code
Parameter display
P07.05 selection in
rectification state
15 parameters can be displayed in operation and stopping state: DC bus voltage (V), grid frequency (Hz),
input voltage (V), input current (A), input power factor (%), active current component (%), reactive current
component (%), input terminal state, output terminal state, AI1 (V), AI2 (V), AI3 (V), input apparent power
(kVA), input active power (kW) and input reactive power (kVar).
Detailed parameter description
0~65535
Detailed parameter description
0: No operation
1: Upload parameters to the keypad
2: Download parameters to the local
Detailed parameter description
0:No function
1: Press QUICK/JOG to switch the
displayed function code to the left
2: Reserved
3: Quick debugging
Detailed parameter description
0: Valid when keypad control
1: Valid when keypad and terminal
control
2: Valid when keypad and
communication control
3: Always valid
Detailed parameter description
0~0xFFFF
-32-
Goodrive3000 series PWM rectifier
Setting range
0~65535
Setting range
0~2
Setting range
0~3
Setting range
0~3
Setting range
0~0xFFFF
Default
0
Default
0
Default
0
Default
3
Default
0x000F
