INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 52

Goodrive3000 series medium voltage inverters
Function
Name
code
filtering time
S1 terminal
P05.04
function selection
S2 terminal
P05.05
function selection
S3 terminal
P05.06
function selection
S4 terminal
P05.07
function selection
P05.08
Reserved
P05.09
Reserved
P05.10
Reserved
P05.11
Reserved
Delay time of S1
P05.12
switching-on
Delay time of S1
P05.13
switching-off
Delay time of S2
P05.14
switching-on
Delay time of S2
P05.15
switching-off
Delay time of S3
P05.16
switching-on
Delay time of S3
P05.17
switching-off
Delay time of S4
P05.18
switching-on
Delay time of S4
P05.19
switching-off
P05.20
Reserved
P05.21
Reserved
P05.22
Reserved
P05.23
Reserved
P05.24
Reserved
P05.25
Reserved
P05.26
Reserved
P05.27
Reserved
P05.28
AI1 lower limit
AI1 lower limit
P05.29
corresponding
setting
P05.30
AI1 upper limit
Detailed parameter
description
0: No function
1: Run
2: Fault reset
3: External fault
4: Reserved
5: Run enabling
6: Reserved
7~12: Reserved
13: Total electricity
consumption cleared
14: Accumulative power
maintain
15: Reserved
0.000~60.000s
0.000~60.000s
0.000~60.000s
0.000~60.000s
0.000~60.000s
0.000~60.000s
0.000~60.000s
0.000~60.000s
0.00V~P05.30
-100.0%~100.0%
P05.28~10.00V
-51-
Goodrive3000 series PWM rectifier
Setting
Default Modify No.
range
1
2
0
0~15
0
0
0
0
0
0.000~60.000 0.000s
0.000~60.000 0.000s
0.000~60.000 0.000s
0.000~60.000 0.000s
0.000~60.000 0.000s
0.000~60.000 0.000s
0.000~60.000 0.000s
0.000~60.000 0.000s
0.00~P05.30 0.00V
-100.0~100.0 0.0%
P05.28~10.00 10.00V
◎
54.
◎
56
◎
57
◎
55.
●
56.
●
57.
●
58.
●
59.
○
60.
○
61.
○
62.
○
63.
○
64.
○
65.
○
66.
○
67.
●
68.
●
69.
●
70.
●
71.
●
72.
●
73.
●
74.
●
75.
○
76.
○
77.
○
78.
