INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 31

Goodrive3000 series medium voltage inverters
Function
Name
code
P06.13 AO1 output selection
P06.14 AO2 output selection
Function
Name
code
Lower output limit
P06.15
AO1
Lower limit
P06.16 corresponding AO1
output
Upper output limit
P06.17
AO1
Upper limit
P06.18 corresponding AO1
output
AO1 output filtering
P06.19
time
P06.20 Lower output limit 2 -100.0%~P06.22
Lower limit
P06.21 corresponding AO2
output
P06.22 Upper output limit 2 P06.20~100.0%
Upper limit
P06.23 corresponding AO2
output
AO2 output filtering
P06.24
time
The function code defines the relationship between the output value and analog output. When the output
exceeds the range, it will be calculated at the upper limit or lower limit value.
Detailed parameter description
0: Null
1: The set value of the DC voltage
(AC1140V, 100% corresponds to
3000V)
2: The actual value of the DC voltage
(AC1140V, 100% corresponds to
3000V)
3: Valid value of input voltage (100%
corresponds to 2*Vn)
4: Valid value of input current (100%
corresponds to In*2)
5: Input power (100% corresponds to
2*Vn*In)
6: Input power factor (%)
7: Grid frequency value (100%
corresponds to 100.0Hz)
8~20: Reserved
Detailed parameter description
-100.0%~P06.17
-10.00V~10.00V
P06.15~100.0%
-10.00V~10.00V
0.000~10.000s
-10.00~10.00V
-10.00V~10.00V
0.000~10.000s
-30-
Goodrive3000 series PWM rectifier
Setting range
0~20
Setting range
-100.0%~P06.17
-10.00V~10.00V
P06.15~100.0%
-10.00V~10.00V
0.000~10.000s
-100.0%~P06.22
-10.00~10.00V
P06.20~100.0%
-10.00V~10.00V
0.000~10.000s
Default
1
2
Default
0.0%
0.00V
100.0%
10.00V
0.000s
0.0%
0.00V
100.0%
10.00V
0.000s
