8.6 Relevant function codes

8.6.1 Relevant function codes of Goodrive3000 series PWM rectifier
Function
Name
code
Local communication
P11.00
address
P11.01 Baud rate setting
P11.02 Check bit setting
P11.03 Response delay
Communication
P11.04
overtime fault
Transmission error
P11.05
processing
Communication
P11.06
processing
8.6.2 Relevant function codes of Goodrive3000 series PWM converter
Function
Name
code
Local communication
P14.00
address
Communication baud
P14.01
rate
Detailed parameter description
1~247
0: broadcast address
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
0: No check (N, 8, 1)for RTU
1: Even check (E, 8, 1)for RTU
2: Odd check (O, 8, 1)for RTU
3: No check (N, 8, 2)for RTU
4: Even check (E, 8, 2)for RTU
5: Odd check (O, 8, 2)for RTU
0~200ms
0.0 (invalid), 0.1~60.0s
0: Report fault and coast to stop
1: Not to report fault and keep working
2: Not to report fault and stop (only in
the communication control mode)
3: Not to report fault and stop (in all
communication control modes)
0x00~0x11
LED ones:
0: Response to write
1: No response to write
LED tens:
0: Reserved
1: Reserved
Detailed parameter description
1~247, 0 is broadcast communication
address
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
-216-
MODBUS protocol
Setting
Default
range
1~247 1
0~5 4
0~5 1
0~200 5
0.0~60.0s 0.0s
0~3 0
0x00~0x11
0x00
Setting
Default
range
1~247 1
0~6 4
