Goodrive3000 series medium voltage inverters
P06 Group Output terminals
Function
Name
code
P06.00 HDO output type
P06.01 Y1 output
P06.02 HDO output
P06.03 Relay RO1 output
P06.04 Relay RO2 output
P06.05 Relay RO3 output
The below table is the options of function parameters which permit selecting the same output terminal
function.
Set value Function
0 Invalid
1 In operation
Forward rotation
2
operation
Reverse rotation
3
operation
Detailed instruction of parameters
0: Open collector output
1: Reserved
0: Invalid
1: In operation
2: Forward rotation operation
3: Reverse rotation operation
4: Jogging operation
5: Inverter fault
6: Frequency degree test FDT1
7: Frequency degree test FDT2
8: Frequency arrival
9: Zero speed running
10: Upper limit frequency arrival
11: Lower limit frequency arrival
12: Ready for operation
13: Pre-excitation
14: Overload pre-alarm
15: Underload pre-alarm
16: Completion of simple PLC step
17: Completion of simple PLC cycle
18: Reserved
19: Reserved
20: External fault valid
21: Reserved
22: Running time arrival
23: MODBUS communication virtual
terminal output
24: PROFIBUS/CANopen
communication virtual terminal output
25: Ethernet communication virtual
terminal output
26~28: Reserved
29: Motor overheat pre-alarm
30: Reserved
There are no functions of output terminals.
When the inverter runs, the frequency output is valid.
When the inverter runs forward, the frequency output is valid.
When the inverter runs reversely, the frequency output is valid.
